CAT Used Loader Front End CAT 950GC Wheel Loader

                  CAT used loader front-end CAT 950GC wheel loader

Model Introduction

The technical parameters of CAT950GC loader are quite rich, and the following are some main technical parameter introductions:
1, Engine parameters
Engine model: Cat ® C7.1
Rated power:
Net power (ISO 9249): 151.0 kW
Rated total power (ISO 143962200 rpm): 168.0 kW
Maximum total power (ISO 143962000 rpm): 171.0 kW
Torque:
Maximum net torque at 1300 rpm: 931.0 N · m
Maximum total torque at 1400 rpm: 1020.0 N · m
Displacement: 7.01 L
Cylinder diameter and stroke: cylinder diameter 105.0 mm, stroke 135.0 mm
These engine parameters indicate that the CAT950GC loader has strong power performance and can meet the operational requirements under various working conditions.
2, Whole machine parameters
Working mass of the whole machine: 18676 kg
Bucket capacity: 2.5 m ³ to 4.4 m ³ (specific capacity may vary depending on configuration)
Rated load capacity: 5000 kg (some data shows 168 kg, but usually the load capacity is much greater than this, which may refer to data under specific conditions)
Driving speed:
Forward 1st gear: 7.0 km/h
Forward 2nd gear: 12.5 km/h
Forward 3rd gear: 22.0 km/h
Forward 4th gear: 34.0 km/h
Reverse 1st gear: 7.0 km/h
Reverse 2nd gear: 12.5 km/h
Reverse 3rd gear: 22.0 km/h
These machine parameters reflect the overall performance and operational capability of the CAT950GC loader, such as working weight, bucket capacity, driving speed, etc., which are important indicators for measuring its work efficiency and applicability.
3, Hydraulic system parameters
Steering system pump type: piston
Maximum pump displacement of the implement system (2200 rpm): 248.0 L/min
Maximum work pressure:
At 50 ± 1.5 L/min: 27900.0 kPa
At 70 L/min (optional third function): 20680.0 kPa
Hydraulic cycle time:
Lift from transport position: 6.1 seconds
Total cycle time: 10.1 seconds
Lowering, unloaded, and floating descent: 2.8 seconds
Unload at maximum lift position: 1.2 seconds
The parameters of the hydraulic system are directly related to the operational efficiency and performance of the loader. The CAT950GC loader adopts a load sensing hydraulic system, which can provide just the right hydraulic flow and pressure according to the operation requirements, thereby improving operation efficiency and reducing fuel consumption.
4, Other parameters
Tire specifications: Optional tires include 23.5-25 16PR, L3 (Triangle) 23.5R25 ★★, L3 (Triangle) 23.5R25 ★, L3 (Bridgestone), etc
Cab protection structure: ROPS/FOPS roll over protection structure/anti falling object protection structure complies with ISO 3471 and ISO 3449 Level II standards
Maintenance and refueling capacity:
Cooling system: 48.0 L
Transmission: 45.0 L
Differential and final drive (front): 40.0 L
Differential and final drive (rear): 38.0 L
Crankcase: 20.0 L
Hydraulic oil tank: 120.0 L
Fuel tank: 290.0 L
These parameters cover the tire specifications, cab safety performance, and maintenance related information of the CAT950GC loader, providing users with a comprehensive understanding and reference.
In summary, the CAT950GC loader is highly favored in the market for its powerful power performance, efficient operation capability, and good safety performance.



The CAT950GC loader is a powerful construction machinery. Let me give you a detailed introduction to its key points:
Powerful: It is equipped with Cat ® The C7.1 engine provides efficient power and an idle management system to reduce fuel consumption.
Hydraulic system: It adopts a load sensing hydraulic system, which can provide just the right hydraulic flow and pressure according to the operation requirements, further improving operation efficiency and reducing fuel consumption.
Design features: The overall design emphasizes durability and reliability, such as its Z-shaped rod connecting rod geometry that provides excellent pile penetration and high digging force.
Easy to operate: The driver's cabin is spacious and comfortable, easy to operate, and equipped with humanized designs such as air conditioning system and adjustable seats, allowing the driver to maintain comfort even during long hours of work.
Widely used: This loader is very suitable for various working conditions such as material stacking, truck loading, and material handling, and is a powerful assistant in engineering construction

Technical Parameters:

Brand	Caterpillar
Product model	CAT950GC
Operating weight of the entire machine (kg)	15698
Bucket capacity (m ³)	2.5-4.2
Engine Name	Cat® C7.1
Oil type	Diesel Oil
Cooling method	water-cooling
Cylinder diameter × Travel	105×135(mm )
Bucket width	3145(mm)
Wheelbase	3450(mm)
Overall height	3600(mm)
Rated power (Kw/rpm)	151
Walking mode	Wheel
advantage	Original engine, high quality and low price, with free operation manual







Product Photos:
